9.5" ARB Intensity LED Light (Flood) (AR32F)

Product Description

Flood Beam

DESIGN & DEVELOPMENT:

In 2009 ARB engineers started a development program to produce an ARB driving light with a completely new design incorporating the latest LED technologies.

Unlike light bars that were growing in popularity, ARB required a light that was compatible with current bull bar designs and traditional driving light mounting points. They also needed to be a legal fitment which, in many states, light bars are not.

Many ARB customers prefer a combination of a spot and spread driving light due to the various driving conditions encountered in general off-roading. Most LED light bars on the market are considered great lights for slower off road driving where the ability to see great distances is not so critical. For ARB’s new light to compete with the best the market can offer in Halogen and HID lighting, it needed to give not only the broad flood beam associated with light bars but also a spot beam with the ability to penetrate longer distances.

Integral to the design was the need for the light to be robust and suited to the conditions encountered off-road like the constant vibrations of corrugated roads, animal strikes and the ability to be submersed. With the general abuse that off-road driving can dish out, the light also needed to be serviceable.

During the development stage, many advances in LED and optics design meant that the LED array and circuitry changed numerous times. With many tens of thousands to be invested in tooling, this meant that the design of the light body needed to be ‘future proofed’ so that further advances in technology would not require re-tooling.

FITTING NOTES:

Existing wire harness or optional ARB harness part number 3500520 required for installation.

SPECIFICATIONS:

• Submersible up to 9.5 ft.
• High pressure cast A360 aluminium body.
• Unbreakable polycarbonate lens.
• UV stable moulded polycarbonate lens cover.
• Multiple position stainless steel mount.
• Durable UV Stable polyester powdercoat
• Gore breather.
• IP68 Certified.
• Deutsch DT-06 waterproof connectors.
• MIL810-STDG vibration certified
• RoHS compliant.
• 10-36 V DC input.
• 90 Watts.
• Amp draw 6.25A @ 14.4V.
• 32 LEDs.
• 8200 raw Lumens.
• Color temperature: 6500 Kelvin
• Lux @ 10m (33Ft) – 2250 (spot) 770 (flood).
• 20° full width flood.
• 10° full width spot.
• Over/under voltage protection.
• 50,000+ Hour LED life span.
• Zero UV emissions .
• Operating temp: -40°F to +145°F
• Protected against RFI/EMC interference.
• Integrated thermal management.
• Weight 3.1Kg / 6.8Lb complete.
• Made in the USA

COOLING:

The pressure cast aluminium housing acts as a heat sink to draw heat generated from the electronics away from the LED array, thus increasing efficiency and life of the LEDs. Cooling fins cast into the rear of the housing increase the cooling surface area of the light body by a massive 200%

SECURITY:

Each light has a cap screw pivot bolt with tamper proof TORX® security fastners used on the adjuster nut for improved security. The main mounting bolt has a 12 x 1.75 thread which accepts the traditional style security nut and Key as used with IPF lights (available separately).

ELECTRONICS:

The heart of the light is its electronics. Using SMD type Osram LEDs for increased efficiency and brightness, the circuit board sits deep within the light body,offering protection to the advanced circuitry while mounting directly to the cast housing for optimum heat transfer and cooling efficiency.

OPTICS:

The advanced Patent design optics incorporate both a reflector and lens to control the light emitted from the LED with 93% efficiency. Designed to offer different light projection patterns, they are the only components that differ between the flood and spot model lights with the flood offering 20° spread and spot a 10° beam.

ADVANCED SEALING:

A unique molded rubber seal sits between the polycarbonate lens and cast aluminium body, creating a watertight and dust proof seal to allow the light to achieve an IP68 rating - meaning complete protection against dust ingress and submersion beyond 9.75 ft. To allow expansion of the heated air within the light and suction caused by rapid cooling if immersed, the light is fitted with a Gore® membrane breather which allows the light to breathe without moisture ingress.

CLEAR COVER:

Manufactured from 3.5mm injection moulded polycarbonate and hard coated for scratch resistance, the clear cover is standard fitment providing the ultimate protection from impacts. Being 100% optically clear, it does not effect light output performance. A warning appears on the outer rim of the cover stating - ‘Warning: High output light source. Do not look directly into optics when light is operating’.

VIDEO:

Sold Individually

Manufacturer - ARB

ARB is Australia’s largest manufacturer and distributor of 4x4 accessories. ARB have an international presence, with an office in the US and an export network that extends through more than 80 countries around the globe. ARB philosophy, however, has never wavered from its original course – quality, reliability and practicality above all else.

ARB's range of 4WD accessories has been specifically designed to suit your vehicle and ensure you're prepared for any off road adventure you choose to take on. All ARB products are tested to the highest standards and subject to a comprehensive minimum two year warranty, ARB deliver exceptional quality and service giving you piece of mind.
